Configuring ExoNodeClass and ExoNodePool

This guide walks you through configuring ExoNodeClass and ExoNodePool for Exostellar Karpenter (version 2.x).

Overview

Before submitting workloads to your cluster, two primary components must be configured:

  • ExoNodeClass defines settings relating to AWS and xcompute profiles.

  • ExoNodePoolenables features and defines sets of nodes that Exostellar Karpenter can create.

Sample Configuration

YAML
apiVersion: karpenter.k8s.exo/v1alpha1
kind: ExoNodeClass
metadata:
  name: class-a
spec:
  xcompute:
    nodeImageName: "k8s-131"
    version: "xspot-3.2.2"
  securityGroupSelectorTerms:
    - tags:
        installer: x-install-<cluster-name>   # Update with your cluster name.
  subnetSelectorTerms:
    - id: "subnet-083b46ca34c707209"
---
apiVersion: exokarpenter.sh/v1beta1
kind: ExoNodePool
metadata:
  name: pool-a
spec:
  disruption:
    consolidateAfter: 1m
    consolidationPolicy: WhenEmpty
  template:
    spec:
      nodeClassRef:
        kind: ExoNodeClass
        name: class-a
      requirements:
        - key: "karpenter.k8s.exostellar/instance-family"
          operator: In
          values: ["m5"]
      exostellar:
        workloadOptimizer:
          enabled: true
        infrastructureOptimizer:
          enabled: true
      taints:
        - key: exokarpenter.sh/x-compute
          effect: NoSchedule
          value: "true"

ExoNodeClass CRD

Field Name

Field Description

Default Value

subnetSelectorTerms

subnetSelectorTerms are the terms to select subnets. Multiple terms are OR'd.
Fields in the same term are AND’d.

Terms can be id or a tag.

N/A (required value)

subnetSelectorTerms.Id

Id is an ID matching a subnet.

Example:

CODE
spec:
  subnetSelectorTerms:
    - id: "subnet-09fa4a0a8f233a921"
    - id: "subnet-0471ca205b8a129ae"

type: string

N/A

subnetSelectorTerms.Tags

Tags is a map of key/value tags used to select a subnet.

Specifying '*' for a value selects all values of the given tag key.

N/A

securityGroupSelectorTerms

securityGroupSelectorTerms are the terms to select security groups. Multiple terms are OR'd. Fields in the same term are AND’d.

Terms can be id, name, or tag.

N/A (required value)

securityGroupSelectorTerms.Id

Id is an ID matching a security group.

type: string

N/A

securityGroupSelectorTerms.Name

Name is a security group name matching a security group.

type: string

N/A

securityGroupSelectorTerms.Tags

Tags is a map of key/value tags used to select a security group.

Specifying '*' for a value selects all values of the given tag key.

N/A

xcompute

xcompute specifies xcompute-related settings

N/A (required value)

xcompute.version

version is the xspot version of the controllers and workers.

Must follow this regex pattern: ^xspot-[0-9]+.[0-9]+.[0-9]+$

type: string

N/A (required value)

xcompute.nodeImageName

nodeImageName is the image that nodes should use. Should match an image name on EMS.

type: string

N/A (required value)

xcompute.nodeVolumeSizeGb

NodeVolumeSizeGb is the size (Gb) of the volume for the node.

type: int

10

xcompute.logPath

logPath is the log filepath on the EMS.

type: string

/xcompute/logs

xcompute.enableBalloon

enableBalloon enables or disables VM self-ballooning. Dynamically adjusts memory allocation within VM to optimize performance and resource utilization.

type: bool

true

xcompute.enableHyperthreading

enableHyperthreading enables or disables hyperthreading. Allows a physical core to act as two logical cores.

true

xcompute.maxControllers

maxControllers is the maximum controllers that can be deployed in each profile defined by this class and a referencing ExoNodePool.

type: int

10

xcompute.prefixCount

prefixCount is the prefix count for the VM naming convention.

type: int

3

xcompute.tags

tags are key-value tags to be attached to worker and controller EC2 instances.

{}

xcompute.controller

controller specifies controller-related settings.

listed below

xcompute.controller.instanceProfile

instanceProfile is the iam instance profile for the controller.

type: string

““ (default value is set by helm flag)

xcompute.controller.instanceType

instanceType is the instance type of the controller.

type: string

c5.large

xcompute.controller.volumeSizeGb

volumeSizeGb is the size of the controller's volume.

type: int

100

xcompute.controller.tags

tags are key-value tags to be attached to controller EC2 instances.

{
exostellar.xspot-role: xspot-controller
}

xcompute.worker

worker specifies worker-related settings.

listed below

xcompute.worker.instanceProfile

instanceProfile is the iam instance profile for the worker.

type: string

““ (default value is set by helm flag)

xcompute.worker.instanceTypes

instanceTypes are the on demand instance type families and priorities that can be used to create a worker.

Each entry in the instanceTypes list must match the regex pattern ^[a-zA-z0-9]+:[0-9]+$

type: array[string]

{“m5:0”, “c5:0”, “r5:0”}

xcompute.worker.spotTypes

spotTypes are the spot instance type families and priorities that can be used to create a worker.

Each entry in the spotTypes list must match the regex pattern ^[a-zA-z0-9]+:[0-9]+$

type: array[string]

{“m5:0”, “m5d:0”, “c5:0”, “c5d:0”, “r5:0”, “r5d:0”}

xcompute.worker.tags

tags are key-value tags to be attached to worker EC2 instances.

{
exostellar.xspot-role:xspot-worker
}

userdata

userdata defines the userdata script to be run on the node.

type: string

““

kubelet

kubelet defines args to be used when configuring kubelet on provisioned nodes.

{}

ExoNodePool CRD

Field Name

Field Description

Default Value

template.spec

Template contains the template of possibilities for the provisioning logic to launch a NodeClaim with.

N/A (required)

template.spec.taints

Taints will be applied to the NodeClaim's node.

{}

template.spec.startupTaints

StartupTaints are taints that are applied to nodes upon startup which are expected to be removed automatically within a short period of time, typically by a DaemonSet. StartupTaints are ignored for provisioning purposes.

{}

template.spec.resources

Resources models the resource requirements for the NodeClaim to launch.

{}

template.spec.requirements

Requirements are layered with GetLabels and applied to every node.

Entries consist of a label key, an operator, and a value.

You can define the set of acceptable CPU and memory sizes for the nodes through the karpenter.k8s.exostellar/instance-category, karpenter.k8s.exostellar/instance-family, node.kubernetes.io/instance-type, and karpenter.k8s.aws/instance-cpu label keys using either the In or NotIn operators.

N/A (required)

template.spec.nodeClassRef

NodeClassRef is a reference to an ExoNodeClass that defines provider specific configuration

N/A (required)

template.spec.exostellar

Exostellar configures the workload optimizer (WO) and infrastructure optimizer (IO) settings.

N/A (required)

template.spec.exostellar.workloadOptimizer

WorkloadOptimizer configures Exostellar's workload optimizer.

N/A (required)

template.spec.exostellar.workloadOptimizer.enabled

Enabled enables workload optimizer for the nodes in this pool.

type: bool

N/A (required)

template.spec.exostellar.infrastructureOptimizer

InfrastructureOptimizer configures Exostellar's infrastructure optimizer.

N/A (required)

template.spec.exostellar.infrastructureOptimizer.enabled

Enabled enables infrastructure optimizer for the nodes in this pool.

type: bool

N/A (required)
